TRUMPF
TC 190R
数控冲床 |
|
|
|
|
|
|
|
|
|
|
PRODUCT DETAIL |
机床介绍 |
|
|
|
Maker:
TRUMPF
|
品牌：
TRUMPF
|
| Model:
TC 190R
|
型号：
TC 190R
|
| M.O.Y:
1997 |
产年：
1997 |
| Axis Travel:
|
主轴行程：
|
| Spindle Speed:
|
主轴转速： |
| Control:
TRUMAGRAPH CC220 CNC
|
控制系统：
TRUMAGRAPH CC220 CNC
|
Specification Description
| FRAME DESIGN |
C-FRAME |
| PRESS CAPACITY |
16.5 TON |
| TYPE OF PUNCHING FORCE |
HYDRAULIC |
| X AXIS TRAVEL |
80" |
| Y AXIS TRAVEL |
40" |
| THROAT DEPTH |
40" |
| NUMBER OF TURRET STATIONS |
10 STATION LINEAR MAGAZINE |
| TYPE OF CNC CONTROL |
TRUMAGRAPH CC220 CNC |
| TYPE OF CLUTCH & BRAKE |
FULLY HYDRAULIC |
| MAXIMIM MATERIAL THICKNESS |
.250" |
| TABLE AXIS FEED RATE |
4,300 IPM |
| STROKES PER MINUTE ON 1" MOVE |
300 SPM |
| STROKE PER MINUTE NIBBLE |
420 SPM |
| NUMBER & SIZE OF AUTO INDEX STATIONS |
10 (3") |
| TYPE OF TURRET TOOLING |
TRUMPF |
| AUTOMATIC SHEET REPOSITIONING |
YES |
| APPROX. WEIGHT |
15,000 LBS |
最大冲切厚度 1/4''（英寸）
冲压力 16、5 TON
控制 TRUMAGRAPH CC220 CNC
冲压类型 液压 |
|
|
