Technical data:
turning diameter 720 mm
turning length 3000 mm
control Weiler CNC Steuerung
turning dia. over face-slide 430 mm
turning dia. in gap 780 mm
length of gap 160 mm
spindle bore 106 mm
spindle taper DIN 55027 Gr. 11
face slide travel 410 mm
longitudinal stroke 3050 mm
spindle turning speed range 1 - 1800 U/min
feeds 0,01 - 3 mm/U
rapid travel - longitudinal/face 7 / 3,5 m/min
power capacity 22 kW
weight of the machine ca. 5,9 t
dimensions of the machine ca. 5,0 x 2,0 x 1,9 m
With:
- coolant
- quick change tool holder
- steadies:3 pieces
- oil-mist-extractor
- 3-jaw manual chucks: 2 pieces
- faceplates: 2 pieces
|
