Technical data:
turning diameter 170 mm
turning length 600 mm
control FANUC 0T/8
centre distance 600 mm
bed width 280 mm
vert. movement Z-axis 400
movement of X-axis 160 mm
rapid traverse X-axis 1 m/min
rapid traverse Z-axis 1,6 m/min
tailstock quill diameter 70 mm
quill adjustment 190 mm
spindle hollow 60 mm
total power requirement 15 kW
weight of the machine ca. 2,9 t
dimensions of the machine ca. 2,5 x 1,3 x 1,8 m
|
