Technical data:
turning diameter 350 mm
turning length 850 mm
control OSP 5000 L-G
controlled axis 4
travel -x axis 245 mm
travel -z axis 520 mm
turning speed range - stepless 40 - 3500 U/min
feed in x - axis 0 - 3500 mm/min
feed range Z-direction 0 - 7000 mm/min
rapid travel - longitudinal/face 15/12 m/min
turret (x-stations) oben 12 fach
turret (x-stations) unten 10 fach
total power requirement 60 kW
weight of the machine ca. 7 t
dimensions of the machine ca. 2,9 x 1,9 m
|
