Machining Center Vertical |
DECKEL MAHO
DMU 70 V
卧式加工中心 |
|
|
|
|
|
|
|
|
|
|
PRODUCT DETAIL |
机床介绍 |
|
|
|
Maker:
DECKEL MAHO
|
品牌：
DECKEL MAHO
|
| Model:
DMU 70 V
|
型号：
DMU 70 V
|
| M.O.Y: 2000 |
产年： 2000 |
| X-Y-Z:
550 mm×750 mm×550 mm
|
主轴行程:
550 mm×750 mm×550 mm
|
| CNC-control Heidenhain TNC 430 |
30 ATC |
| |
|
Technical details
1 used CNC-machining centre - universal - 5 axis brand DECKEL-MAHO model DMU 70 V start up Dez. 2000 travel X-axis 750 mm Y-axis 550 mm Z-axis 550 mm table surface clamping 750 x 550 mm table axis NC-RT 360000 x 0.001deg. - swifelling range 200 degmax weight of workpiece ca. 350 kg spindle motor power 20 KW spindle speed range 20 - 12000 rpm coolant supply through-the-spindle coolant 40 bar tool taper SK 40 automatic tool changer 30 ATC feed max. 20000 mm/min. rapid 40 m/min. CNC-control Heidenhain TNC 430 accessories:NC-swivelling-rotary tableautomatic tool changerthrough-the-spindle coolant 40 baroil coolant supply for table and spindle coolant supply with high pressure pumpfull protection cabinechip conveyorRotoclearand more...
|
