Technical details
Clamping dimensions of pallet table: 800 x 800 mmDivision of turning table - pallet: 72 x 5°Working stroke - longitudinal, cross, vertical:1000 x 750 x 750 mmSpindle taper: ISO 50Distance of spindle axis to table clamping surface: 0 - 750 mmSpindle speed - 48 steps:9 - 2000 rpmTravel speed (continuous regulation): 1 - 3000 mm/minRapid travel speed: 7000 mm/minMax. weight of workpiece: 2500 kgNumber of tools in magazine: 50Spindle motor: 23,5 kWDimensions (L x W x H):4490 x 6010 x 3885 mmWeight: 20500 kgControl system: NS720
|
