Technical details
x-travel 630 mm
z-travel 550 mm
y-travel 500 mm
rotary table tiltable 360 Grad
flute distance 80 mm
width of T-slots 12 mm
T-slots 5 Stk.
type of control Bosch Mikro 8 Z
distance spindle center to table 90-590 mm
distance spindle nose and table 150-700 mm
tool taper DIN 69871 / A40
weight of tools max. 15 kg
tool piece magazine with 116 Pl?tze
size of pallet 500 x 400 mm
spindle turning speed range 50-6400 U/min
spindle taper SK 40
rapid traverse 10 m/min
power capacity at 100 % load max. 10 kW
total power requirement 37 kW
weight of the machine ca. 15 t
dimensions of the machine ca. 6,4 x 6,7 x 2,8 m
|
