Technical details
x-travel 630 mm
y-travel 600 mm
z-travel 650 mm
Pallet dimension 500x500 mm
spindle speeds 12000 U/min
rapid traverse X-axis 32 m/min
rapid traverse Z-axis 32 m/min
Number of tool station 60 SK40
spindle drive 22 kW
control Fanuc MSC 516 MB
numbers of pallets 3
table load 0,5 t
working diameter max. 610 mm
table index 1,0 °
max. tool length 360 mm
max. tool weight 12 kg
tool changing time 1,3 sec
total power requirement 50 kVA
weight of the machine ca. 14 t
dimensions of the machine ca. 3x4,5x3,4 m
|
