Table:
Max. Pallet Load ................................. 880 Lbs.
Feed:
Cutting Feed ..................................... 0.1-197 In/Min
Rapid Traverse ................................... 512 In/Min
Minimum Input Increment .......................... 0.0001"
A.T.C.:
Tool Capacity .................................... 30 Tools
Max. Tool Diameter ............................... 4.5
Max. Tool Length ................................. 12"
A.P.C.:
Pallet Size ...................................... 16" Square
Spindle Head/Spindle Nose ........................ NT40
Spindle Speeds ................................... 45-4500 RPM
Spindle Motor .................................... 7 1/2 HP
Tool Shank ....................................... CAT 40
Max. Tool Weight ................................. 22 Lbs.
Approximate Dimensions ........................... 132"L x 77"W x 103"H
Approximate Machine Weight ....................... 11,000 Lbs.
|
