Max. X-Axis Travel ....................................... 19.685"
Max. Y-Axis & Z-Axis Travel .............................. 15.750"
Pallet Loading Weight .................................... 660 Lbs.
Pallet Size .............................................. 15.75" X 15.75"
Pallet Index Angle (Count: 72) ........................... 5 Deg.
Spindle Speeds (Variable) ................................ 45 To 5000 RPM
Spindle Motor ............................................ AC 11
Spindle Taper ............................................ N.S.T. 40
Screw Conveyor Motor ..................................... 60 W
Cutting Oil Tank Capacity ................................ 26 Gallons
Maximum Tool Diameter .................................... 4.9213"
Maximum Tool Length ...................................... 11.811"
Maximum Tool Weight ...................................... 22 Lbs.
|
