Pallet Dimensions (19.68 x 19.68") ............... 500 x 500 MM
Max. X Axis Travel ............................... 600 MM
Max. Y Axis Travel ............................... 500 MM
Max. Z Axis Travel ............................... 550 MM
Pallet Loading Weight ............................ 500 Kgf
Spindle Taper .................................... N.S.T. No. 50
Spindle Speed (Op: 30~4000) ...................... 30~3150 RPM
Spindle Motor (30 Min/Continuous) ................ 15/11.5
Requisite Floor Space (Width X Depth) ............ 4350 x 3616 MM
Machine Weight (Including APC) ................... 8500 Kgf
Maximum Tool Dia. (When Adjacent Tool Loaded) .... 0-2120 MM?
Maximum Tool Dia. (No Adjacent Tool Loaded) ...... 0-1150 MM (Determined
Maximum Tool Length .............................. 350 MM
Maximum Tool Weight .............................. 15 Kgf
Magazine Tool Capacity ........................... 24
|
