Pallet size................................630mm x 630mm
Number of Pallets..........................2
X - Axis Travel............................850mm
Y - Axis Travel............................700mm
Z - Axis Travel............................750mm
Max. Table Load............................1200 kgs
Rapid Traverse X, Y & Z....................15,000 mm / min
Cutting Feed Rate..........................0.1 to 4,000 mm / min
Distance Spindle Center Line to Top of Center.........150 mm
Distance from Spindle Nose to Table Center 150 mm / 900 mm
Spindle Power..............................15/20 HP
Spindle RPM Range..........................15-4500
Spindle Taper..............................ISO - 7/24 No. 50
Spindle Diameter...........................100 mm
Spindle Torque Max. .......................103.7 kg
Automatic Tool Changer.....................180 Tools
Machine Weight.............................Approx: 15 Ton Metric
|
