Machining Center Vertical |
NORTE-KLESSMANN
VS 800
立式加工中心 |
|
|
|
|
|
|
|
|
请点击小图看大图 |
|
PRODUCT DETAIL |
机床介绍 |
|
|
|
Maker:
NORTE-KLESSMANN
|
品牌：
OKUMA
|
| Model:
MX-45VAE
|
型号：
MX-45VAE
|
| M.O.Y:
1992 |
产年：
1992 |
| Table:
|
工作台：
|
| |
|
| 工作台行程(横向×纵向×垂直) |
工作台行程(横向×纵向×垂直)
|
| Siemens 3M4C |
Siemens 3M4C |
|
Technical details
x-travel 1000 mm
y-travel 400 mm
z-travel 400 mm
table-size 850x470 mm
spindle cone ISO 40x SK40
rapid traverse 25 m/min
T-slots 3
T - slots - width 18 mm
spindle turning speed range 20-6300 U/min
control Siemens 3M4C
no. of tools in the magazine 40 Stück
power requirement 7,5 kW
total power requirement 10 kW
weight of the machine ca. 4,7 t
dimensions of the machine ca. 3,7x3,7x3,1 m
|
