Machining |
AMC
R-3000-CNC
数控磨床 |
|
|
|
|
|
|
|
|
|
|
PRODUCT DETAIL |
机床介绍 |
|
|
|
Maker:
AMC
|
品牌：
AMC
|
Model:
R-3000-CNC
|
型号：
R-3000-CNC
|
| M.O.Y: 1986 |
产年： 1986 |
| Axis Travel: |
主轴行程：
|
| Spindle Speed:
1-5000 mm/min |
主轴转速：
1-5000 mm/min
|
| Control:
|
控制系统：
|
Max. distance between chucks mm / inch 3.050 / 120
Max. distance between centres mm / inch 3.000 / 118
Max. swing over table mm / inch 680 / 27
Max. weight of workpiece between chucks kg / lb 2.500 / 5.510
Max. grinding length mm / inch 3.000 / 118
Max. grinding diameter with new grinding wheel mm / inch 610 / 24
Table speeds mm/min / inch/min 1-5.000 / 0.04-197
Headstock spindle speeds,variable rpm 2-500
Headstock motor kW / hp 7 / 9.5
Grinding wheel motor kW / hp 17 / 23
Max. grinding wheel diameter mm / inch 813 / 32
Max. grinding wheel width mm / inch 100 / 4
Diameter of grindingwheel bore for hub mm / inch 305 / 12
Max. tailstock quill mm / inch 70 / 2.8
Working space(working machine) mm / inch 9.800 x 2.900 / 386 x 114 |
|
|
