Machining Center Vertical |
AMADA
virpos358king
数控冲床 |
|
|
|
|
|
|
|
|
|
|
PRODUCT DETAIL |
机床介绍 |
|
|
|
Maker:
AMADA |
品牌：
AMADA
|
| Model:
PEGA 345Q
|
型号：
PEGA 345Q
|
| M.O.Y:
1995 |
产年：
1995 |
| Axis Travel:
|
主轴行程：
|
| Spindle Speed:
|
主轴转速： |
| Control:
FANUC 04PC CNC
|
控制系统：
FANUC 04PC CNC
|
Specification Description
| FRAME DESIGN |
BRIDGE |
| PRESS CAPACITY |
33 TON |
| TYPE OF PUNCHING FORCE |
HYDRAULIC |
| X AXIS TRAVEL |
80" |
| Y AXIS TRAVEL |
50" |
| THROAT DEPTH |
50" |
| NUMBER OF TURRET STATIONS |
58 |
| TYPE OF CNC CONTROL |
FANUC 04PC CNC |
| TYPE OF CLUTCH & BRAKE |
FULLY HYDRAULIC |
| MAXIMIM MATERIAL THICKNESS |
1/4" |
| TABLE AXIS FEED RATE |
4,455 IPM |
| STROKES PER MINUTE ON 1" MOVE |
375 HPM |
| STROKE PER MINUTE NIBBLE |
600 HPM |
| NUMBER & SIZE OF AUTO INDEX STATIONS |
2 (4 1/2") & 2 ( 1 1/4") |
| TYPE OF TURRET TOOLING |
THICK STYLE |
| AUTOMATIC SHEET REPOSITIONING |
YES |
| APPROX. WEIGHT |
39,000 LBS |
控制 FANUC 04PC CNC
最大冲切厚度 1/4''（英寸）
冲压类型 液压
冲压力 33 TON |
|
|
