Power Draw Bars for Each Spindle
GE Fanuc 11-M CNC Control with CRT, MDI Keyboard, RS 232 Port & Tape Reader
Hand Held X Y Z Remote Jog Control
Hardened & Ground Ways
Central Lube System
(2) 15 HP Main Motors
3 HP Hydraulic Motor
Wired 3 Phase, 230 Volts/460 Volts
Dimensions:
Machine: 149" LR x 84" FB x 109" H
Power Supply: 77" LR x 22" FB x 92" H
Control: 26" LR x 30" FB x 64" H
Hydraulic Unit: 27" LR x 22" FB x 34" H Weight: Approx. 20,000 Lbs
|
